Technical Specifications
| Operating input voltage | : | 120-300Vac; 50/60 Hz |
| Input current | : | 210mA (230VAC @full load) |
| Power factor | : | 0.98 |
| THD | : | <10% |
| Efficency | : | >88% |
Output parameters
| Output voltage | : | 24VDC |
| Output current range | : | 0-2500mA |
| Accuracy in output parameter | : | ± 3% |
| Load current | : | Automatically drop |
| Solar energy | : | Yes |
Features
- Short circuit protection, Open circuit protection, Phase loss protection.
- Input high voltage protection 300Vac, Low voltage protection 120Vac.
- Surge protection.
- Step control regulator solution.
- Remote control can be controlled remotely.
- Natural air cool design, Highly reliable.
- Compatible with 24VDC motor, Customized according to DC motor voltage.
- HRI developed and copied the correct design, using advance BLDG algorithm.
- Reserved solar port, support expansion function.
Speed control 5th gear
| I Step Cap. | Watt | RPM |
| No.1(Min) | 5.62W | 120RPM |
| No.2 | 11.4W | 210RPM |
| No.3 | 19.6W | 263RPM |
| No.4 | 24.5W | 298RPM |
| No.5(Max) | 40.5W | 380RPM |
Remote control
- Timer control: Press the button once and the driver indicator flashes once, indicating that the timer has started. To cancel the timer, press the same button again and the LED will flash twice. As a result, the timer has been canceled. Or use the Close button.
- Nature: Press the button, and the LED flashes once. Once natural wind mode is activated. The speed will gradually change from 1 to 5. Press any speed button.
- Do not need to run, please press the close button.
- Two AAA size batteries are required. If the product is not used for a long time, please remove the batteries.
